This universal wall hung toilet frame offers a smart and robust solution for mounting all pipework and cistern systems associated with your toilet. This fantastic and innovative product comes from Livari Bathrooms. This product is WRAS approved and comes with a dual flush cistern.

Application

• For wall-hung WC
• For mounting in front of a support wall or in to a plasterboard construction
• For floor thickness 0-200 mm
• For installation of wall-hung WC pans with a connecting pitch of 180 mm or 230 mm

Features

• W510mm x H1130mm x D160-200mm
• Adjustable sliding anchor feet and a spring-lock system, with a range of 0-200 mm
• Visible marks for both leveling and the centerline
• Sliding rail holder for the waste connector can be set to eight positions between 0-93 mm
• Angle valve with the ability to connect to the Mepla piping system
• The frame allows the anchoring to a separate sufficiently strong plasterboard partition or in front of the bearing wall
• The installed module is sealed with a plasterboard panel and there is no need for any additional fixing or anchor elements
• The construction of polystyrene insulation prevents condensation forming on the surface of the tank and dampens the vibrations from the tank into the building structure
• Prepared for connecting a bracket with a DG 1/2” conversion for bidet seats and sprays
• Dual flush, independently adjustable with hygienic reserve
• Suitable for installation of remote or sensor flushing
